Product Line

Gas Range

Power Type

NG

Size

30"

Installation Type

Free-Standing

Factory

Springfield

Color

Stainless Steel

Cooktop

Cooking Surface Type

Gas

Grate Material

Cast Iron

Grate Quantity

3

Grate Style

Continuous

Sealed Burners

Yes

Cooktop Performance

Right Front Element Burner

18000 BTU

Right Rear Element Burner

5000 BTU

Left Front Element Burner

14000 BTU

Left Rear Element Burner

10000 BTU

Center Rear Element Burner

10000 BTU

Cooking Controls

Bake

Yes

Broil

Yes

Child Lock

Yes

Clock

Yes

Cook Time

Yes

Delay Start

Yes

Keep Warm

Yes

Kitchen Timer

Yes

Off

Yes

Oven Light

Yes

Preheat

Yes

Start

Yes

Steam Clean

Yes

Temperature Display

Yes

Timer On / Off

Yes

Up / Down Arrow

Yes

Cooking Controls Function

Change between Continuous Bake Setting or 12-Hour Energy Saving Feature

Yes

Delayed Bake

Yes

Program Fahrenheit or Celsius

Yes

Silent Control Panel

Yes

Oven

Bake Element

17000 BTU

Broil Element

1400 Watts

Cleaning System

Yes

Number of Rack Positions

6

Oven Interior Color

Midnight Black

Oven Light Quantity

1

Oven Light Type

Halogen

Oven Light Watts

40 Watts

Rack Position Type

Embossed

Rack Type 1

Flat

Rack Type 1 Quantity

2

Drawer

Drawer Type

Storage

Display

Control Location

Front

Display Interface Color

White

Display Type

Capacitive Touch

Dimensions and Volume

Minimum Height

35 5/8"

Maximum Height

36 3/8"

Width

30"

Depth

26"

Depth With Door 90° Open

47 1/4"

Depth With Handle

28 1/2"

Oven Interior Height

17 5/8"

Oven Interior Width

25 3/16"

Oven Interior Depth

19 7/8"

Oven Capacity

5.1 Cu. Ft.

Electrical Specifications

Amps @ 120 Volts

12 Amps

Voltage Rating

120 V

Installation

Adjustable Leveling Legs

Yes

General Specifications

Frigidaire Fit Promise

Yes

Product Weight

160 lbs

Prop 65 Label

Yes

Warranty - Labor

1 Year

Warranty - Parts

1 Year

AB-1200

Information available at frigidaire.com/en/ab1200

Certifications and Approvals

ADA Compliant

Yes

CSA Listed

Yes
